AVANTI 540 - RAFT FOR 12 PEOPLE

RA3254_R

Price
€3.530,99
€3.530,99

Designed to accommodate 12 people , the Avanti 540 combines a generous 540×210 cm (107 cm interior) with 52 cm diameter tubes and five removable 35.5 cm diameter thwarts for efficient crew handling. Its self-bailing finned floor, Leafield Marine A6 overpressure valve, and 4+5+1 air chamber configuration enhance safety and comfort, while 16 D-rings, 6 grab handles, and a 300 cm flat frame facilitate onboard organization. Lightweight for its class (87 kg) , it supports a maximum load of less than 1750 kg.

Color
Available In Stock
Free return
2-year warranty
AVANTI 540 - RAFT FOR 12 PEOPLE
  • Overview
  • Specifications
BENEFITS

KEY STRENGTHS

  • REMOVABLE THWART

    For maximum versatility, the thwarts are removable thanks to a system of bars.

  • FOOT CUP SHOES

    To ensure comfort, support and safety, the Avanti range is equipped with foot cups that fit snugly.

  • CARRYING HANDLE

    Reinforced handles, doubled and sewn at the base to ensure easy, comfortable and durable transport.

  • 10 CM RAGING BAND

    For optimal side protection and extended service life, the range is equipped with a rubbing strip.

  • RINGS D

    To ensure the safety of the entire crew, a lifeline is positioned around the perimeter of the raft.

  • Number 1 in Europe

    Thanks to the expertise accumulated by Aquadesign since 1988, the AVANTI range of PVC rafts is number 1 in Europe.

dimensions, weight and specs

Technical specifications

Capacity
12 Personnes
Length
540 cm / 17'7"
Width
210 cm / 83"
Inner width
107 cm / 42"
Longueur maximale du cadre plat
300 cm / 9'8"
Tube diameter
52 cm / 20"
Thwarts
5 Thwarts amovibles
Thwart diameter
35.5 cm / 14"
Rocker Avant
31 cm / 12.2" (Mesure sol/ base des tubes) - 84 cm / 33" (Mesure sol/ sommet des tubes)
Rocker Arrière
31 cm / 12.2" (Mesure sol/ base des tubes) - 84 cm / 33" (Mesure sol/ sommet des tubes)
Number of air chambers
4 + 5 + 1
Safety valve
1 Leafield – A6
Self-bailing system
Trous auto videur
D-rings
16
Handles
6
Weight
87 kg / 192 lbs
Maximum Load
<1750 kg / <3858 lbs
AVANTI RANGE

REINFORCED CONSTRUCTION

  1. 1000 Dtex fabric tube
  2. Superior reinforcement of the tubes with 1100 Dtex fabric
  3. Upper part of the finned bottom made of 1000 Dtex fabric
  4. Lower part of the finned bottom made of 2000 Dtex fabric
  5. Lower tube lining in abrasion-resistant fabric
  6. Lower tube reinforcement with a high-strength grooved band
DESCRIPTION, MATERIALS & ADVICE

LEARN MORE

The AVANTI 540 Aquadesign raft is designed for organizations seeking a spacious, stable, and durable 12-person inflatable boat. Measuring 540 cm long and 210 cm wide (107 cm internal width), it offers comfortable space for passengers and equipment, while the 52 cm diameter tubes ensure buoyancy and stability. The seating is arranged around five removable 35.5 cm diameter supports, allowing for adjustments to suit different outing configurations.

The hull features a self-bailing finned bottom and a rocker profile defined by two measurements (Aquadesign method): 31 cm from the bottom to the base of the tubes and 84 cm from the bottom to the top, both at the bow and stern. On board, there are 16 D-rings for lifelines and tie-downs, 6 carrying handles, and a maximum flat frame length of 300 cm for gear organization. Safety is ensured by a Leafield Marine A6 overpressure valve and a 4+5+1 air chamber redundancy system.

The premium construction emphasizes durability: indicative fabrics of 1450 g/m² for the floor and 1100 g/m² for the tubes, 1000 DTEX PVC tubes with 1000 DTEX top reinforcement, finned floor in 1000 DTEX (top) and 2000 DTEX (bottom), 1000 DTEX lining under the tubes up to the rubbing strake. Despite its size, the entire unit remains easy to handle, weighing in at 87 kg for a maximum load of less than 1750 kg.

Why choose the AVANTI 540 Aquadesign
• Excellent value for money: 100% premium PVC construction, 2x cheaper than Hypalon
• Versatility: pronounced rocker and finned bottom to adapt to all rivers
• Modularity: 5 removable thwarts Ø 35.5 cm, flat frame 300 cm
• Durability: 1000/2000 DTEX reinforcements, 1450/1100 g/m² fabric, continuous self-draining

1000 Dtex PVC fabric tube, 1100 Dtex PVC top reinforcement, 1000 and 2000 Dtex PVC fabric finned bottom, abrasion-resistant fabric, grooved band, 10cm rubbing strip

Weight/m2 of the tube fabric: 1100 g / 39 oz (This is the weight per square meter of the tube fabric; this value is an indicator of the fabric's strength.)

Weight/m2 of the background fabric: 1450 g / 51 oz (This is the weight per square meter of the background fabric; this value is an indication of the fabric's strength.)

A well-maintained AVANTI raft will provide you with years of safe adventures. To preserve its performance and durability, adopt these best practices.

  • Rinse after each outing

After each use, rinse your AVANTI thoroughly with clean water.

✔️ Remove sand, mud and debris to prevent premature wear of the PVC.

✔️ Use a soft sponge to avoid scratching the coating.

  • Dry completely before storing

✔️Never store your raft wet.

✔️ Let it dry completely in the shade, as prolonged exposure to the sun accelerates the aging of the fabric.

✔️ Check that all chambers and the bottom are completely dry to prevent mold and bad odors.

  • Suitable storage

Store your AVANTI in a dry, ventilated place, away from extreme temperature variations.

✔️ Avoid any proximity to heat sources (radiator, engine).

✔️ Protect it from rodents and insects.

  • Pressure and inflation

Maintain the recommended pressure of 2.5 PSI .

✔️ Overinflation weakens seams and valves.

✔️ In warm weather, slightly reduce the pressure to compensate for air expansion.

  • Preventive maintenance

✔️ Regularly inspect valves, seams and bonding areas.

✔️ Repair any micro-perforations immediately using a suitable kit.

To access the manual, click on the following link: Avanti range manual
