AVANTI 420 - RAFT FOR 8 PEOPLE

RA3253_Y

Price
€2.668,99
€2.668,99

Designed to accommodate 8 people , the AVANTI 420 combines a premium construction that's half the price of Hypalon with a more flexible fabric for increased flex and maneuverability. Measuring 420 cm long and 193 cm wide (95 cm interior), it features three removable 28 cm diameter thwarts , an inflatable floor with fins, and self-bailing scuppers. Safety is ensured by a Leafield A6 overpressure valve and a 4+3+1 air chamber configuration. With 14 D-rings, 6 grab handles, and a 200 cm flat frame, it remains lightweight (62 kg) with a maximum load capacity of less than 1050 kg.

Color
Available In Stock
Free return
2-year warranty
AVANTI 420 - RAFT FOR 8 PEOPLE
  • Overview
  • Specifications
BENEFITS

KEY STRENGTHS

  • REMOVABLE THWART

    For maximum versatility, the thwarts are removable thanks to a system of bars.

  • FOOT CUP SHOES

    To ensure comfort, support and safety, the Avanti range is equipped with foot cups that fit snugly.

  • CARRYING HANDLE

    Reinforced handles, doubled and sewn at the base to ensure easy, comfortable and durable transport.

  • 10 CM RAGING BAND

    For optimal side protection and extended service life, the range is equipped with a rubbing strip.

  • RINGS D

    To ensure the safety of the entire crew, a lifeline is positioned around the perimeter of the raft.

  • Number 1 in Europe

    Thanks to the expertise accumulated by Aquadesign since 1988, the AVANTI range of PVC rafts is number 1 in Europe.

dimensions, weight and specs

Technical specifications

Capacity
8 Personnes
Length
420 cm/ 13'8"
Width
193 cm / 76"
Inner width
95 cm / 37"
Longueur maximale du cadre plat
200 cm / 79"
Tube diameter
49 cm / 19"
Thwarts
3 Thwarts Amovibles
Thwart diameter
28 cm / 11"
Rocker Avant
31 cm /12.2" (Mesure sol/ base des tubes) - 83 cm / 33" (Mesure sol/ sommet des tubes)
Rocker Arrière
31 cm /12.2" (Mesure sol/ base des tubes) - 83 cm / 33" (Mesure sol/ sommet des tubes)
Number of air chambers
4 + 3 + 1
Safety valve
1 Leafield – A6
Self-bailing system
Trous auto videur
D-rings
14
Handles
6
Weight
62 kg / 137 lbs
Maximum Load
<1050 kg / 2315 lbs
AVANTI RANGE

REINFORCED CONSTRUCTION

  1. 1000 Dtex fabric tube
  2. Superior reinforcement of the tubes with 1100 Dtex fabric
  3. Upper part of the finned bottom made of 1000 Dtex fabric
  4. Lower part of the finned bottom made of 2000 Dtex fabric
  5. Lower tube lining in abrasion-resistant fabric
  6. Lower tube reinforcement with a high-strength grooved band
DESCRIPTION, MATERIALS & ADVICE

LEARN MORE

The AVANTI 420 Aquadesign raft is aimed at organizations looking for an 8-person boat that combines onboard space, versatility, and cost-effectiveness. It belongs to a range renowned for its value: premium construction with reinforcements and double layers, half the price of a Hypalon raft, and a more flexible fabric that provides the flex and mobility needed during maneuvers.

With its 420 x 193 cm dimensions and an interior width of 95 cm, the AVANTI 420 offers ample space for crew and equipment. The 49 cm diameter tubes provide reassuring support, while the three removable 28 cm diameter thwarts allow for seat adjustments to suit different configurations. The deck is equipped with 14 D-rings for lifelines and tie-downs, six carrying handles, and self-bailing holes for easy water drainage while underway. The flat frame extends to 200 cm, providing a well-organized workspace.

The hull features an inflatable finned floor, a key element in the range's versatility. For clear performance, Aquadesign specifies the front rocker in two measurements (31 cm from the bottom to the base of the tubes / 83 cm from the bottom to the top) and the rear rocker (28 cm / 79 cm). For safety, the boat is equipped with a Leafield A6 overpressure valve and a 4 + 3 + 1 air chamber redundancy system.

Durability relies on clear material choices: indicative fabric weight of 1450 g/m² for the floor and 1100 g/m² for the tubes, upper tube reinforcement in 1000 DTEX fabric, upper finned section in 1000 DTEX, lower finned section in 2000 DTEX, 1000 DTEX lining from the bottom of the tubes to the rubbing strake, and a ribbed reinforcement band under the tubes. The entire unit remains easy to handle with a weight of 62 kg and a maximum load capacity of less than 1050 kg.

Why choose the AVANTI 420 Aquadesign
• Excellent value for money: premium construction with reinforcements and linings, half the price of hypalon
• Versatile: pronounced rocker and finned bottom to adapt to all rivers
• Lightweight: 62 kg
• Durable: Reinforced tubes and rub rail. Designed to accommodate 8 people, the AVANTI 420 combines a premium construction that's twice as affordable as Hypalon with a more flexible fabric for increased flex and mobility. Measuring 420 cm long and 193 cm wide (95 cm interior), it features three removable 28 cm diameter thwarts, an inflatable floor with fins, and self-bailing scuppers. Safety is ensured by a Leafield A6 overpressure valve and a 4+3+1 air chamber configuration. With 14 D-rings, 6 grab handles, and a 200 cm flat frame, it remains lightweight (62 kg) with a maximum load capacity of less than 1050 kg.

1000 Dtex PVC fabric tube, 1100 Dtex PVC top reinforcement, 1000 and 2000 Dtex PVC fabric finned bottom, abrasion-resistant fabric, grooved band, 10cm rubbing strip

Weight/m2 of the tube fabric: 1100 g / 39 oz (This is the weight per square meter of the tube fabric; this value is an indicator of the fabric's strength.)

Weight/m2 of the background fabric: 1450 g / 51 oz (This is the weight per square meter of the background fabric; this value is an indication of the fabric's strength.)

A well-maintained AVANTI raft will provide you with years of safe adventures. To preserve its performance and durability, adopt these best practices.

  • Rinse after each outing

After each use, rinse your AVANTI thoroughly with clean water.

✔️ Remove sand, mud and debris to prevent premature wear of the PVC.

✔️ Use a soft sponge to avoid scratching the coating.

  • Dry completely before storing

✔️Never store your raft wet.

✔️ Let it dry completely in the shade, as prolonged exposure to the sun accelerates the aging of the fabric.

✔️ Check that all chambers and the bottom are completely dry to prevent mold and bad odors.

  • Suitable storage

Store your AVANTI in a dry, ventilated place, away from extreme temperature variations.

✔️ Avoid any proximity to heat sources (radiator, engine).

✔️ Protect it from rodents and insects.

  • Pressure and inflation

Maintain the recommended pressure of 2.5 PSI .

✔️ Overinflation weakens seams and valves.

✔️ In warm weather, slightly reduce the pressure to compensate for air expansion.

  • Preventive maintenance

✔️ Regularly inspect valves, seams and bonding areas.

✔️ Repair any micro-perforations immediately using a suitable kit.

To access the manual, click on the following link: Avanti range manual
